Preparation of Material Specification Sheet

DWG material export team are delivering a deliverable to procurement and design to for selection of MOC of each component in piping system.

Preparation of Standard PMS

• PMS is a Bible for a Piping Engineer. It consists all about material details, dimension details, type of ends, schedules/thicknesses, branch offs, NDT requirements, various codes / standards being followed etc for all Piping items. Main Piping items detailed out in PMS are listed below :
• Pipes
• Fitting
• Flanges
• Misc Items(Steam Trap / Strainer)etc.
• Bolts
• Gasket
• Valves
